[SItoA] Understanding the Object color mode of the Utility shader

Posted on by
Reply

The Utility shader has an Object color mode that assigns colors to objects based on names. Each shape (for example, a polymesh shape or a curves shape or a box shape) gets a unique color, because each shape has a unique name.

If you’re working with SItoA, you may have noticed that the object color changes with each frame:
utility_color_mode

That’s because SItoA gives shapes names like Elephant.Elephant_Mesh.SItoA.4000, which change with every frame.

MtoA doesn’t use the current frame in shape node names, and neither does HtoA (by default). However, HtoA does provide an option for adding a suffix, like the frame number, to the shape node name.

[SItoA] More about particle shapes

Posted on by
Reply

For the Point, and Sphere particles shapes, you get a single Arnold points node. For example, for the Sphere shape, you’d get a points node that looked something like this:

points
{
 name pointcloud.SItoA.Sphere.5000
 points 54 1 b85POINT
8LLwt8;`)381]^28S`W`8:l)EadWuf8[iB>89m7taW>aAaX=rn8...
 radius 54 1 b85FLOAT
!8Fcb9$$$$Z
 mode "sphere"
 visibility 255
 sidedness 255
 matrix
 1 0 0 0
 0 1 0 0
 0 0 1 0
 0 0 0 1
 shader "Sources.Materials.DefaultLib.Material.standard.SItoA.5000.2.sta_shading_group"
 id 832
}

This particular node is for 54 points in sphere mode. For each point, you get the center position (the points.points parameter) and a radius (the points.radius parameter). If there’s any scaling applied to the particle in ICE, the radius is multiplied by the X scaling of the particle.

For the Point shape, you get an Arnold points node in “disk” mode, with radius = size * X scaling.
points_disc_mode

For the other supported shapes, you get the corresponding Arnold shape.

[SItoA] Arnold, ICE, and Shapes

Posted on by
Reply

particle_shape
SItoA translates ICE particle shapes to native Arnold shapes. The supported particle shapes are already documented here, but here’s a little more information about how they are translated.

ICE Shape Arnold Shape
Point points (mode “disk”)
Disc disk
Rectangle box (with 0 height)
Box box
Sphere points (mode “sphere”)
Cylinder cylinder
Cone cone
Instance Shape ginstance

The Segment, Capsule, and Blob shapes are not supported. SItoA skips them and they are not translated into the Arnold scene source.

Object color mode

Posted on by
Reply

The Arnold Utility shader has an Object color mode, which assigns colors based on shape names. When we say “shapes”, we don’t mean Maya shape nodes; we mean the Arnold shapes.

C:\solidangle\mtoadeploy\2014\bin>kick -nodes | find "shape"
 box                              shape
 cone                             shape
 curves                           shape
 cylinder                         shape
 disk                             shape
 ginstance                        shape
 implicit                         shape
 nurbs                            shape
 plane                            shape
 points                           shape
 polymesh                         shape
 procedural                       shape
 sphere                           shape

All these nodes have a name parameter (for example, polymesh.name) that is a unique string identifier in the Arnold universe. So when you use the Object color mode, you get a unique color for each node.

If you’re using Softimage, note that SItoA puts the frame number into polymesh.name, so you’ll get a different color on each frame if you use the Object color mode. For example, on frame 5 a polymesh might be named “Dog_Mesh.SItoA.5000”, and on frame 6, “Dog_Mesh.SItoA.6000”.

In this render region comparison, you have frame 5 on the left, and frame 6 on the right:
dog_color_mode

In a case like this, you would use the Object ID color mode instead. SItoA automatically assigns unique IDs to the shape nodes (MtoA doesn’t).

[SItoA] Subdivision settings for polygon meshes

Posted on by
Reply

To show you where the polygon mesh subdivision settings are in Softimage, I’m going to start in Arnold and work back into Softimage via SItoA.

So, let’s start with an Arnold polymesh shape, which has a number of subdivision parameters:

C:\solidangle\Arnold-4.1.3.3\bin>kick -info polymesh | find "subdiv"
ENUM          subdiv_type                       none
BYTE          subdiv_iterations                 1
FLOAT         subdiv_pixel_error                0
NODE          subdiv_dicing_camera              (null)
ENUM          subdiv_adaptive_metric            auto
ENUM          subdiv_uv_smoothing               pin_corners
BOOL          subdiv_smooth_derivs              false

In Softimage, you access most of these subdivison parameters by adding an Arnold Parameters property to a polygon mesh (you can’t add new parameters to Softimage built-in objects like a PolygonMesh, so we have to use a custom property).

  • subdiv_iterations
  • subdiv_pixel_error
  • subdiv_adaptive_metric
  • subdiv_smooth_derivs (Shape group)

Other Arnold subdiv parameters are mapped to existing Softimage parameters:

  • subdiv_uv_smoothing is mapped to Smooth when subdividing in the
    Texture Projection Property Editor. If Smooth when subdividing is enabled, then subdiv_uv_smoothing is set to pin_corners; otherwise, it’s set to linear.
  • subdiv_type is mapped to the Subdivision Rule list in the Polygon Mesh property editor. Linear goes to linear, and anything else (XSI-Doo-Sabin, Catmull-Clark) goes to catclark.

Finally, subdiv_dicing_camera is on the Subdivision tab of the global Render Settings.

[SItoA] Uninstalling SItoA

Posted on by
Reply

When you install an addon like SItoA, you may see an error like this the next time you start Softimage:

// ERROR : 2356 - This plug-in is not installed: ArnoldRenderPreferences

That’s because addons like SItoA install custom preferences, which are left behind when you uninstall the addon. At startup, Softimage finds the custom preference but can’t find the plugin that owns the preference (because it’s been uninstalled).

To get rid of this error, go to your Softimage user folder, and delete the Data\Preferences\Arnold Render.preset file.

ArnoldRender.preset

[SItoA] Disabling camera motion blur

Posted on by
3

Starting with version 2.8, SItoA no longer supports the Softimage motion blur property. Instead, you use the Arnold Parameters property to control transformation and deformation motion blur.
arnold_parameters_motion_blur

However, you cannot add an Arnold Parameters property to a camera (at least not using the SItoA custom menus, which will tell you that a camera is “is not a valid Object to add Arnold Parameters to”). Here’s a couple of ways to work around that:

  • Create an Arnold Parameters property on a polygon mesh, and then in the Explorer, drag that property to your Camera.
  • Select your camera and run this Python snippet:
    cam = Application.Selection(0)
cam.AddCustomProperty( "Arnold_Parameters" )
